Shantui SD13 130hp dozer
Features:
---The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation
---The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;
---The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;
---The single control lever can control all blade actions;
---The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;
---The hexahedron cab features wide visibility, and the insulation materials in the cab can reduce noise and vibrations;
---The spin type fuel filter and dust separator, the air filters and the other filtration devices can prolong work time and reduce service time;
---The comfortable cab seat can adjust upward and downward, forward and backward, meeting any positional needs the operator may have;
---Side engine operation and the combination of a drive/brake operation system and foot brake makes overall operation of the bulldozer more rapid and convenient.
Engine
| Type | SSHANGCHAI D6114ZG4B(water cooled, in-line, direct injection and turbo charge) |
| Rated revolution | 1900rpm |
| Rated power | 95.5kw |
| Cylinder number-bore x stroke | 6-114 x 135 |
| Piston displacement | 8.27L |
| Rated fuel consumption | <=228g/kW.h |
| Max. Torque | 674.m/1300rpm |
Undercarriage system
| Type | Swing type of sprayed beam, suspended structure of equalizer bar |
| Carry rollers | 2 each side |
| Track rollers | 6 each side |
| Track type | Single teeth. Dry type |
| Width of track shoes | 460mm |
| Pitch | 190mm |
Hydraulic system
| Max. Pressure | 14MPa |
| Pump type | Gear pump |
| Discharge | 180L/min lated revelation |
| Working cylinder x number | 90mm x2 |
Power transmitting system
| Torque converter | 3-element, 1 stage, 1 phase |
| Transmission | Forced connected, planetary gear |
| Main drive | Spiral bevel gear, splash lubrication |
| Steering clutch | Wet, Multi-disc, spring loaded, hydraulic helping operation, mechanical separating, linking steering brake |
| Steering brake | Wet, floating, band type foot stepping brake with hydraulic helping |
| Final drive | 2-stage speed reduction of spur gear, splash lubrication |
| Blade | Straight-tilt | Angle |
| Min. Ground clearance(mm) | 320 | 320 |
| Operating weight(kg) | 14000 | 14500 |
| Ground pressure(MPa) | 0.064 | 0.064 |
| Gradeability | 30 | 30 |
| Track gauge(mm) | 1880 | 1880 |
| Dozing capacity(m3) | 3.7 | 3.4 |
| Blade height(mm) | 1090 | 915 |
| Blade width(mm) | 3185 | 3745 |
| Max. Drop below ground(mm) | 590 | 590 |
| Max. Tilt adjustment(mm) | 400 | 400 |
Travel speed
| Gear | 1st | 2nd | 3rd |
| Foward(km/h) | 3.2 | 5.9 | 9.8 |
| Reverse(km/h) | 3.9 | 7.1 | 11.9 |
